Specification

• Suitable for use with unvented supplies, combi boilers, gravity and mains pressure systems

---

• Thermal cartridge technology

---

• Temperature stability of +/-2 DegC

---

• Fail safe on hot and cold supplies

---

• Operating pressure range of 0.4 to 5 bar

---

• TMV2 and WRAS approved

---

• Integrated flow diverter

---

Other Info

• Factory pre set temperature: 38 Deg C with max temp stop

---

• Inlet connections: G 3/4 Inch F BSP (valve body)

---

• Max inlet pressure static: 5 bar

---

• Max inlet temperature: 85 Deg C

---

• Min inlet pressure dynamic: 0.4 bar

---

• Min temp to achieve hot or cold fail safe: 15 Deg C

---

• Outlet connections: G 3/4 Inch BSP (top) and G 0.5 Inch BSP (bottom)

---

• System installation: Unvented, pressurised, gravity and combi boilers

---
